The DSi XL is a 4.2 x2 inch 4:3 Proprietary handheld that plays everything up to DS well, made by Nintendo. It came out in March 2010 at $80. Inside is the Custom SoC with 16 MB of RAM.
DSi XL videos
What it plays
Plays up to: DS. Chip: Custom SoC.
Scores out of 100. 100 means the system runs at full speed with no known issues on this device. 80 or more plays well (green), 50 to 79 plays partly (yellow).
What owners say
“After 15 years, I still love my DSiXL! Probably the best D-Pad, overall build quality and buttons ever made.”
“I have a DSi XL and I find the emulators to be not very good.”
“I enjoy my DSi XL but that's because I bought the special edition of 4 swords.”
What the specs mean
Same chip as 4 other handhelds
The Custom SoC also powers the DS, DS Lite, DSi, PlayStation Vita. The same chip means similar speed, though memory and cooling can differ.
Based on: Our handheld database (chip field)
Rating
Original consoles get no RETROPULSE score: it rates handhelds made for emulation.
Good
- Plays everything up to DS well
- Low price
Not so good
- No analog sticks
- PS1 games do not run reliably
- No video out
- Small 1,050 mAh battery
Specs
| Performance | |
|---|---|
| Chip | Custom SoC |
| CPU | ARM946E-S |
| Cores | Single |
| Clock speed | 133 MHz |
| GPU | 2D Graphics Engine |
| RAM | 16 MB SRAM |
| Cooling | No |
| Screen | |
| Size | 4.2 x2" |
| Type | IPS |
| Resolution | 256 × 192 |
| Pixel density | 76 ppi |
| Aspect ratio | 4:3 |
| Touch screen | Yes |
| Dual screen | Yes |
| Controls | |
| D-pad | Cross, Upper placement |
| Analog sticks | No |
| Stick layout | No Thumbsticks |
| Shoulder buttons | No L2/R2 |
| Rumble | No |
| Gyroscope | No |
| Connectivity | |
| Storage | 256 MB NAND flash memory |
| SD card | Yes |
| Wi-Fi | Yes (?) |
| Bluetooth | No |
| USB-C | No |
| Video out | No |
| Headphone jack | Yes |
| Build | |
| Form factor | Clamshell |
| Dimensions | 161 x 91.4 x 21.2 mm |
| Weight | 314 g |
| Battery | 1050 mAh |
| Shell | Plastic |
| Speakers | Front |
| Software | |
| Operating system | Proprietary |
Questions
Can the DSi XL play PS2 games?
Not well. PS2 scores 0 out of 100. It plays everything up to DS well.
Does it have a headphone jack?
Yes.
How big is the battery?
1,050 mAh. The middle Linux and other handheld in our database has 3,000 mAh.
Can it connect to a TV?
No, it has no video out.
How much does the DSi XL cost?
It launched at about $80 in Mar 2010. Prices on the used market change, so check current listings.
Price and newer models
$80 at launch
